6V 225AH

Specs DataSheet PDF

USES OF FFP BATTERIES

• Floor cleaning machines
• Boom lifts
• Golf cars
• Forklift with working platform
• Rides in amusement parks
• Mini electric vehicles

SPECIFICATIONS OF FFP BATTERIES

• Double-terminal batteries.
• Corrosion-resistant, heavy-duty alloy grill.
• High-density positive active substance designed for deep cycle feature
• Carbon-enhanced negative active substance to improve charge acceptance and cycle performance.

Sorin Deep Cycle Battery 6v 225Ah

Brand :  Sorin Deep Cycle
Nominal: Voltage: 6V

Length:  261mm
Width:   181mm
Height:  279mm

Weight:  29Kg
Terminal Type: Embedded Terminal (ET)

Capacity 20Hr:  225Ah
Capacity 5H:  185Ah
Capacity 75A:  115 mins
Capacity 25A: 447 mins

5Hr Capacity by temperature
40 Degree C  105%
30 Degree C 100%
0 Degree C 80%

Material Specifications

Cover style    Individual Fitting Structure
Cover vent Style   Gang Style
Container and cover material Black polypropylene plastic
Case to Cover Seal Method Heat sealing
Inner-Cell Connector Type Through the partion weld
Plate lug weld method  Automated cast-on process
Positive grid material  Antimony lead alloy
Negative grid material  Antimony lead alloy
Separator type   Microporous rubber with glass mat


Phase 1 (Constant-current)
 constant current charge at 20.5~26.6 amperes until the battery voltage measures between 7.14~7.29V/Battery (25°C) on charge voltage.

Phase 2 (Constant-voltage)
 constant voltage charge at 7.14~7.29V/Battery (25°C) until the current measures between 2.05~6.15 amperes.

Phase 3 (Constant-current)
 constant current charge at 2.05~6.15 amperes until the
 battery voltage measures between 7.5~8.1V/Battery
 (25°C) or until dV/dt reaches to less than 0.035.
